RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance

Place of Origin : Sichuan, China

Brand Name : Bonens

Model Number : RI80-5W-5MR

MOQ : 100

Resistance : 10-100kΩ

Resistance Tolerance : ±5%

Type : Cermet resistors

Composition : Ceramic

Temperature Coefficient : 200ppm

Number of Pins : 2

Power Rating : 5W

Inductance : Non-inductive

Coating : Glass glaze

Voltage Type : High Voltage

Rapid Temp Change : ΔR≤ ± (1% R + 0.05Ω)

Climatic Sequence : ΔR≤ ± (5% R + 0.1Ω)

Terminal Strength : ΔR≤ ± (1% R + 0.05Ω)

Solder Heat Resistance : ΔR≤ ± (1% R + 0.05Ω)

Overload Capacity : 2.5x rated power

Contact Now

Product Description
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
Specification
Test items
Testing method
GB / T5729 IEC115-1
Performance requirements
Rapid changes in temperature
Lower category temperature - room temperature - upper category temperature - room temperature, 5 cycles each limit temperature is
kept 30min
ΔR≤ ± (1% R + 0.05Ω)
Climatic sequence
Dry heat - Damp heat, cyclic - cold - Low pressure - cycle heat - DC load DC voltage is applied Length 1min
ΔR≤ ± (5% R + 0.1Ω)
Terminal Strength
Rally test
ΔR≤ ± (1% R + 0.05Ω)
Resistance to soldering heat
Groove welding method, the bath temperature: 350 ± 10 ℃ time: 3.5 ± 0.5s Immersion depth: 2 ± 0.5mm
ΔR≤ ± (1% R + 0.05Ω)
overload
Applying a 2.5 or 2 times the rated power load 5s
ΔR≤ ± (1% R + 0.05Ω)
Steady heat
Applying a DC voltage (limit voltage of the rated voltage or elements) Length 1min
ΔR≤ ± (5% R + 0.1Ω)
Upper category temperature durability
Resistor on the upper category temperature specified duration 1000h
ΔR≤ ± (5% R + 0.1Ω)
Packing & Delivery
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
RI80 5W High Voltage Resistor 10-100kΩ ±5% Tolerance
Sichuan Qixing Electronics Co., Ltd. is specialized in manufacturing high-power resisters, wire-wound potentiometers, trimmer potentiometers, rotary carbon potentiometers, precision parts and so on ...... Engaged in civil and war industrial products for many years, we enfore ISO9001, ISO2000 quality control systems strictly. Our products are widely used in electronic communication products, instrument measuring appliances, cable TV equipments, electrician products, color television, color console, video and audio products and many other products. In order to maintain a leading position in the industry, we have further strengthened our product development ability. Moreover, we took the lead in introducing the world leading high temperature polymerization furnaces from the USA to establish ceramic resistance element production line. QIXING has 500 workers at present, among whom we are proud of our 56 professionals(35 of them got over 10 years' experience in potentiometer/ high-power resister). To satisfy our customers' needs, we provide product design and developing servises, OEM services, best aftersales servises and give best support once customer got a new idea. Providing massive acknowledged products to the war and civil industry units, our company has made certain
contribution to the motherland national defense and the thriving of our economy. "Technical innovation, striving for perfection, keeping on improving, continuously satisfying customers" is our company's quality policy, and "let customers be satisfied completely" is our goal. All our staff members are zealously creating a magnificent tomorrow with wit and diligence!
FAQ
1. who are we?
We are based in Sichuan, China, start from 2005,sell to Domestic Market(70.00%),Western Europe(8.00%),North America(5.00%),South
Asia(3.00%),Eastern Asia(3.00%),South America(2.00%),Southern Europe(2.00%),Eastern Europe(2.00%),Mid East(2.00%),Southeast
Asia(2.00%),Oceania(1.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Potentiometer , Resistor, EMI Filter, Knob, Switch

4. why should you buy from us not from other suppliers?
Our company is establsihed in 2005 ,which mainly develops and manufactures different types of potentiometer,ac dc noise filter,
and ceramic power resistor and is a professional manufacturer ensuring high quality, best services and best price.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Western Union,Cash;
Language Spoken:English,Chinese
